AVT – Air Velocity and Temperature Sensor

$ 286.00$ 325.00

AVT – Air Velocity & Temperature Sensor
Download:
AVT Manual
Clear

Description

AVT – Air Velocity and Temperature Sensor

The AVT is an electronic air velocity and temperature transmitter for air and non-combustible gases with optional relay output.

AVT series air velocity transmitters are engineered for building automation in the HVAC/R industry. The AVT measures air velocity and temperature, with field selectable range and output options in a single device. Designed with a duct mount probe and adjustable collar suitable for round or rectangular ducts.
AVT series devices include:
• 3 field selectable measurement ranges for air velocity, selectable via jumper.
• Separate readings and outputs for air velocity and temperature.
• Proportional output options include: voltage (0–10 V) and current (4–20 mA).
AVT series device options offer:
• Back lit display
• Field adjustable relay
Air Velocity Ranges: 0-400fpm, 0-2000fpm, 0-4000fpm (ft/min)
Temperature Measuring Range: 32-122F
AVT Model Selection:
  • AVT Air Velocity and Temperature Sensor, No Display, No Relay
  • AVT-D Air Velocity and Temperature Sensor, With Display, No Relay
  • AVT-D-R Air Velocity and Temperature Sensor, With Display, With Relay

Additional information

Weight 2 lbs
Dimensions 14 × 6 × 6 in
Model

AVT

Display / Relay

No Display, No Relay, With Display, No Relay, With Display, With Relay
